  • Capacity


    • Capacity (Cooling, Btu/hr)17,060


    • Capacity (Heating, Btu/hr)20,472


    • Capacity (Cooling, Min - Max, Btu/hr)4,265 - 20,472


    • Capacity (Heating, Min - Max, Btu/hr)3,378 - 22,178


    • Capacity (Cooling, kW)5


    • Capacity (Heating, kW)6


    • Capacity (Cooling, Kcal/hr)4,300


    • Capacity (Heating, Kcal/hr)5,160





  • Energy Efficiency


    • EER (Cooling, W/W)3.23


    • COP (Heating, W/W)3.3


    • EER (Cooling, Btu/hW)11.01





  • Noise Level


    • Noise Level (Indoor, High/Low, dBA)41 / 26


    • Noise Level (Outdoor, High/Low, dBA)52





  • Electrical Data


    • Power Source(Φ/V/Hz)1 / 220 - 240 / 50


    • Power Consumption(Cooling, W)1,550


    • Power Consumption(Heating, W)1,820


    • Operating Current(Cooling, A)7.2


    • Operating Current(Heating, A)9





  • Physical specification


    • Net Dimension (Indoor, WxHxD, ㎜*㎜*㎜)896 x 260 x 275


    • Net Dimension (Outdoor, WxHxD, ㎜*㎜*㎜)790 x 545 x 285


    • Gross Weight (Indoor, kg)11.5


    • Gross Weight (Outdoor, kg)41.5


    • Net Weight (Indoor, kg)10


    • Net Weight (Outdoor, kg)40





  • Technical Information


    • Piping Length (Max, m)30


    • Piping Height (Max, m)15


    • SVC Valve (Liquid (ODxL))6.35


    • SVC Valve (Gas (ODxL))12.7


    • Moisture Removal (l/hr)1.8


    • Air Circulation (Cooling, ㎥/min)14


    • Refrigerant (Type)R410A


    • Low Ambient (Cooling, ℃)-10 - 46


    • Low Ambient (Heating, ℃)-15 - 24


    • Outdoor Unit (Compressor Type)BLDC


    • Outdoor Unit (Anti-Corrosion Fin)Yes


    • Outdoor Unit (Multi-Channel Condensor)Yes





  • Air Flow


    • Optimal Single BladeYes


    • Air Direction Control (Up/Down)Auto


    • Air Direction Control (Left/Right)Auto


    • Air Flow Control Step (Cool/Fan)4 Steps





  • Air Purification


    • Auto Clean (Self Cleaning)Yes


    • Virus DoctorYes


    • Easy filterYes





  • Convenience


    • Smart wifiNo


    • Filter Cleaning IndicatiorYes


    • Indoor Temp. DisplayYes


    • Display On/OffYes


    • Beep On/OffYes


    • 24-Hour TimerYes


    • Auto ChangeoverYes


    • Auto RestartYes





  • Operating Mode


    • 2 Step CoolingYes


    • Fast CoolYes


    • Comfort CoolYes


    • Good SleepYes


    • Single User ModeYes


    • Fan ModeYes


    • QuietYes
